Heat Conducting Metal from Metal Injection Molding Supplier
Heat Conducting Metal from Metal Injection Molding Supplier
Share
Advantages:
● Low thermal expansion coefficient
● Good thermal conductivity
● Low density
● Easy processing
Metal injection moulding of complex shaped parts
MIM technology enables the production of complex shaped parts according to the same manufacturing principle as plastic injection moulding. We inject a mixture of a metallic material with a plastic binder. This is followed by a debinding process in which the plastic is eliminated from the workpiece. Finally, the mechanical properties of the material are restored during sintering.
● Maximum length: 150mm
● Maximum weight: 120 grams
● Thickness: from 0.5 mm
● Opening: from 0.5 mm
● Minimum radius: 0.10 mm
● General roughness: Ra > = 0.4
Tolerances:
● 1 to 6 mm +/- 0.04 mm
● 6 to 12 mm +/- 0.05 mm
● 12 to 25 mm +/- 0.08 mm
● 25 to 50 mm +/- 0.10 mm
● Materials: Stainless steel (17-4PH, AISI 304L/316L, etc.), iron-nickel alloys (FeNi2, FeNi8, etc.), magnetic iron compounds, titanium, steel.
● Other materials are available on request.
● Quantity: from sample to mass production 500 pcs onwards
