MIM 4605 (Quenched & Tempered, High Hardness) for Metal Injection Molding Process Services

MIM 4605 (Quenched & Tempered, High Hardness) for Metal Injection Molding Process Services

MIM 4605 is a premium material that has been quenched and tempered to achieve high hardness, making it ideal for metal injection molding process services. Its superior strength and durability provide top-notch performance, ensuring the success of your projects. Trust MIM 4605 for all your metal injection molding needs.

Low-Alloy Steel

Iron-based alloys, also known as low-alloy steels, are often used in structural applications because of their high hardness and performance strength.

MIM-4605

MIM 4605 has excellent strength and good ductility through the MIM process, and has a wide range of applications in the automotive, consumer goods and hand tool industries.

MIM-4605 Ingredients

MIM-4605

iron

silicon

carbon

nickel

molybdenum

weight percentage

BaL.

1.00

0.40-0.60

1.50-2.50

0.20-0.50

MIM-4605 Mechanical Properties

Material

density

tensile strength

Yield strength (0.2%)

Impact strength

hardness

Elongation (within %25.4mm)

MIM-4605

≥7.50g/cm3

≥600Mpa

≥400Mpa

70J

≥90 HV10

≥5%

The alloy can be quenched and tempered heat treated to obtain a variety of strengths and wear resistance properties. Generally, we can produce the following low and high hardness special types:

MIM-4605 Low Hardness Mechanical Properties

Material

density

tensile strength

Yield strength (0.2%)

Impact strength

hardness

Elongation (within %25.4mm)

MIM-4605

≥7.5g/cm3

1151Mpa

1034Mpa

38J

36 HRC

≥3%

MIM-4605 High Hardness Mechanical Properties

Material

density

tensile strength

Yield strength (0.2%)

Impact strength

hardness

Elongation (within %25.4mm)

MIM-4605

≥7.5g/cm3

1655Mpa

1480Mpa

55J

48 HRC

≥2%
